RubberMax® Super and Super Pro
RM Biltrite® RubberMax® Super Heavy Duty Anti-Abrasion Rubber is made with a proprietary compound base of premium natural rubber for strong resistance to cut, abrasion, impact, corrosion, and tear. Pure natural rubber is an excellent material for wear-heavy environments like the mining and aggregate industries due to its inherently high strength, resilience, and abrasion resistance. RM Biltrite® Rubbermax® Super rubber has high tensile strength, greater elasticity, and excellent wear-resistance, resulting in unmatched performance. Available with 1 or 2 sides sanded and/or 1 side with neoprene bonding layer.
Features
-
Excellent abrasion and cut resistance
|
-
Excellent tensile strength
|
-
High resilience and wear-resistance
|
-
High elasticity and tear strength
|
Applications
|
TECHNICAL SPECIFICATIONS |
|
Name |
RubberMax®
Super 35* |
RubberMax®
Super 38 |
RubberMax®
Super 38 Pro |
RubberMax®
Super 50 |
RubberMax®
Super 60 |
RubberMax®
Super 70 |
|
Item ID |
M1200-35 |
M1300-38 |
M1350-38 |
M1300-50 |
M1300-60 |
M1300-70 |
Hardness
ASTM D2240 |
Shore
A
(± 5) |
35 |
38 |
38 |
50 |
60 |
70 |
Tensile
Strength ASTM D412
(min) |
psi |
3600 |
3626 |
3916 |
3481 |
3916 |
3336 |
|
MPa |
25 |
25 |
27 |
24 |
27 |
23 |
Elongation
ASTM D412 |
% |
750 |
900 |
810 |
650 |
700 |
450 |
Tear
ASTM D624 |
lb/in |
- |
246 |
280 |
280 |
560 |
392 |
|
kg/cm |
- |
44 |
50 |
50 |
100 |
70 |
Abrasion
ASTM D5963 |
mm3
(min) |
80 |
50 |
60 |
80 |
60 |
60 |
Specific Gravity
ASTM D297 |
g/cm3 |
0.97 |
0.98 |
1.02 |
1.05 |
1.10 |
1.15 |
|
Resilience |
% (max) |
- |
73 |
70 |
60 |
70 |
43 |
|
Modulus |
psi |
- |
580 |
624 |
798 |
870 |
1015 |
|
MPa |
- |
4 |
4 |
6 |
6 |
7 |
|
Temperature Range |
°F |
-40 - +158 |
-40 - +167 |
-40 - +167 |
-40 - +167 |
-40 - +167 |
-40 - +167 |
|
°C |
-40 - +70 |
-40 - +75 |
-40 - +75 |
-40 - +75 |
-40 - +75 |
-40 - +75 |
|
Food Grade |
Yes |
- |
- |
- |
- |
- |
|
Color |
Red, Blue, or Tan |
Red, Beige, or Orange |
Red, Beige, or Orange |
Red, Beige, or Orange |
Red, Beige, or Orange |
Red, Beige, or Orange |
|
ROLL DIMENSIONS |
|
|
Widths |
Thicknesses |
Lengths |
|
U.S. |
48” |
54” |
60” |
1/16” |
3/32” |
1/8” |
3/16” |
1/4” |
3/8” |
1/2” |
3/4” |
1” |
33’ |
|
Metric |
121.9 cm |
137.2 cm |
152.4 cm |
1.6 mm |
2.4 mm |
3.2 mm |
4.8 mm |
6.4 mm |
9.5 mm |
12.7 mm |
19.1 mm |
25.4 mm |
10.1 m |
Custom sizes and colors available upon request
